Product Overview
Condition: REFURBISHED
Availability: Inventory Available - May Be Limited
Cisco Catalyst 9600 Series Line Card - Up to 24 ports of 40 GE or 12 ports of 100 GE nonblocking - plug-in module (C9600-LC-24C)
| Device Type | Switch - 24 ports |
| Enclosure Type | Plug-in module |
| Ports | 24 x 100 Gigabit QSFP28 / 40 Gigabit QSFP28 |
| Performance | Bandwidth: 2.4 Tbps |
| Features | IPv6 support, Access Control List (ACL) support, Quality of Service (QoS), Media Access Control Security (MACsec) |
| Compliant Standards | IEEE 802.3, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x |
| Interfaces | 24 x 100Gbit/40Gbit LAN QSFP28 |
| MTBF | 710,750 hours |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN55024, AS/NZS 60950-1, ICES-003 Class A, Laser Class 1, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, AES-256, CAN/CSA C22.2 No. 60950-1, EN 300 386 V1.6.1, EN61000-3-2, EN61000-3-3, EN 55022 Class A, EN 300 386, EN 55032 Class A, CISPR 32 Class A, TCVN 7189 Class A, V-3 Class A, TCVN 7317 |
| OS Required | Cisco IOS XE 16.11.1 |
| Width | 15 in |
| Depth | 15.7 in |
| Height | 1.7 in |
| Weight | 7.67 lbs |
| Min Operating Temperature | 23 å¡F |
| Max Operating Temperature | 113 å¡F |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Min Storage Temperature | -40 å¡F |
| Max Storage Temperature | 158 å¡F |
| Humidity Range Storage | 10 - 95% (non-condensing) |
