Description
Condition: REFURBISHEDAvailability: Inventory Available - But May Be Limited
Cisco 1 Port Serial WAN Network Interface Card (NIM-1T)
Cisco Gigabit Ethernet WAN Modules bring high-density Ethernet connectivity to the Cisco 4000 Series Integrated Services Routers (ISRs). Providing maximum flexibility, the modules accelerate applications such as Ethernet WAN access, inter-VLAN routing, and high-speed connectivity to LAN switches and servers.
| Device Type | Serial adapter |
| Form Factor | Plug-in module |
| Ports | RS-232/449/530/V.35/X.21 x 1 |
| Connectivity Technology | Wired |
| Data Link Protocol | RS-232, RS-530, X.21, V.35, RS-449, RS-530A |
| Data Transfer Rate | 8 Mbps |
| Interfaces | 1 x RS-232/449/530/V.35/X.21 |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, JATE, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, CAN/CSA C22.2 No. 60950-1, VCCI Class A, EN 300386, CNS 13438 |
| Width | 3.5 in |
| Depth | 7.2 in |
| Height | 1.3 in |
| Min Operating Temperature | 32 å¡F |
| Max Operating Temperature | 104 å¡F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Designed For | Cisco 4451-X, 4451-X Application Experience, 4451-X Integrated Services Router, 4451-X Integrated Services Router Security Bundle, 4451-X Integrated Services Router Voice and Video Bundle, 4451-X Integrated Services Router Voice Security Bundle |
